| Nominal size | Finished size | Screen size | Glass size | O.T |
|---|---|---|---|---|
| 5'0 × 6'8 | 59 1/2 × 79 1/2 | 29 1/4 × 76 5/8 | 26 × 70 9/16 | 1" |
| 5'0 × 6'8 (US) | 58 1/2 × 79 1/2 | 29 1/4 × 76 5/8 | 25 1/2 × 70 9/16 | 1" |
| 5’0 × 6’10 | 59 1/2 × 81 1/2 | 29 1/4 × 78 5/8 | 26 × 72 9/16 | 1" |
| 5’0 × 8’0 | 59 1/2 × 95 1/2 | 29 1/4 × 92 5/8 | 26 × 86 9/16 | 1" |
| 6’0 × 6’8 | 71 1/2 × 79 1/2 | 35 1/4 × 76 5/8 | 32 × 70 9/16 | 1" |
| 6’0 × 6’8 (US) | 70 1/2 × 79 1/2 | 35 1/4 × 76 5/8 | 31 1/2 × 70 9/16 | 1" |
| 6’0 × 6’10 | 71 1/2 × 81 1/2 | 35 1/4 × 78 5/8 | 32 × 72 9/16 | 1" |
| 6’0 × 8’0 | 71 1/2 × 95 1/2 | 35 1/4 × 92 5/8 | 32 × 86 9/16 | 1" |
| 8’0 × 6’8 | 95 1/2 × 79 1/2 | 47 1/4 × 76 5/8 | 44 × 70 9/16 | 1" |
| 8’0 × 8’0 | 95 1/2 × 95 1/2 | 47 1/4 × 92 5/8 | 44 × 86 9/16 | 1" |
| Nominal size | Finished size | Screen size | Glass size | O.T |
|---|---|---|---|---|
| 7’6 × 6’8 | 88 3/4 × 79 1/2 | 29 1/4 × 76 5/8 | 26 × 70 9/16 | 1" |
| 7’6 × 6’10 | 88 3/4 × 81 1/2 | 29 1/4 × 78 5/8 | 26 × 72 9/16 | 1" |
| 7’6 × 8’0 | 88 3/4 × 95 1/2 | 29 1/4 × 92 5/8 | 26 × 86 9/16 | 1" |
| 9’0 × 6’8 | 106 3/4 × 79 1/2 | 35 1/4 × 76 5/8 | 32 × 70 9/16 | 1" |
| 9’0 × 6’10 | 106 3/4 × 81 1/2 | 35 1/4 × 78 5/8 | 32 × 72 9/16 | 1" |
| 9’0 × 8’0 | 106 3/4 × 95 1/2 | 35 1/4 × 92 5/8 | 32 × 86 9/16 | 1" |
| 12’0 × 6’8 | 142 3/4 × 79 1/2 | 47 1/4 × 76 5/8 | 44 × 70 9/16 | 1" |
| 12’0 × 6’10 | 142 3/4 × 81 1/2 | 47 1/4 × 78 5/8 | 44 × 72 9/16 | 1" |
| 12’0 × 8’0 | 142 3/4 × 95 1/2 | 47 1/4 × 92 5/8 | 44 × 86 9/16 | 1" |
| Nominal size | Finished size | Screen size | Glass size | O.T |
|---|---|---|---|---|
| 10’0 × 6’8 | 117 1/4 × 79 1/2 | 29 1/4 × 76 5/8 | 26 × 70 9/16 | 1" |
| 10’0 × 6’10 | 117 1/4 × 81 1/2 | 29 1/4 × 78 5/8 | 26 × 72 9/16 | 1" |
| 10’0 × 8’0 | 117 1/4 × 95 1/2 | 29 1/4 × 92 5/8 | 26 × 86 9/16 | 1" |
| 12’0 × 6’8 | 141 1/4 × 79 1/2 | 35 1/4 × 76 5/8 | 32 × 70 9/16 | 1" |
| 12’0 × 6’10 | 141 1/4 × 81 1/2 | 35 1/4 × 78 5/8 | 32 × 72 9/16 | 1" |
| 12’0 × 8’0 | 141 1/4 × 95 1/2 | 35 1/4 × 92 5/8 | 32 × 86 9/16 | 1" |
| 16’0 × 6’8 | 189 1/4 × 79 1/2 | 47 1/4 × 76 5/8 | 44 × 70 9/16 | 1" |
| 16’0 × 6’10 | 189 1/4 × 81 1/2 | 47 1/4 × 78 5/8 | 44 × 72 9/16 | 1" |
| 16’0 × 8’0 | 189 1/4 × 95 1/2 | 47 1/4 × 92 5/8 | 44 × 86 9/16 | 1" |
